SPECIFICATIONS

Brand Name: yamahas

Condition: New,New

Control system: Tiller control

Cooling system: water-cooling

Cylinders: 2

Dimensions (L x W x H) (mm): 112*53*38cm

Engine: 2 STROKE

Engine Position: OUTBOARD

Engine type: 15 HP

Fuel Type: Gasoline

Max speed(r/min): 4500-5500

Mixing ratio: Fuel:Oil=50:1

Model Number: 15 HP

Place of Origin: Zhejiang, China

Product Name: Outboard Motor

Purpose: Rubber boat outboard engine

Recommended fuel: #92Lead-free gasoline

Starting system: Manual start

Trim and tilt system: Manual tilt

Warranty: 12 Months

Technical parameters		Outboard motor model parameters 2-stroke Water Cooling
Engine Type	In-line 2
Displacement [cm3]	246
Bore x Stroke[mm]	56*50
Max. Prop Shaft Output [kW (ps)] @r/min	11.0 (15) @5000
Fuel Induction System	Carburetor
Engine Transom Height[mm (inch)]	S: 440 (17.3), L: 567 (22.3)
Dry Weight [kg]	36-38
Starting System	Manual Starter
Controls	Tiller Handle
Tilt System	Manual Tilt
Lubrication System	Pre-mixed Fuel and Oil

The difference between short shaft and long shaft

Short axis: Axis 381 mm (15 inches) (15 inches) The height of the adaptation boat is 44 cm (including) below the ship

Long shaft: Axial length 508 mm (20 inches) A ship that adapted to the height of the pupa board 45 cm (including) -55 cm (inclusive)

The difference between the two rushes and the four rush stabs

Fuel economy type: The four -stroke machine with the horsepower can save about 30%of fuel fuel than the two -range machine. Gasoline and motor oil: The fuel fuel of the two -strokes is a mixed oil of gasoline oil. The outside of the two -stroke ship does not have special oil irrigation holes. It does not need to irrigate the oil for lubrication, but lubricates when burning. The four -stroke machine fuel is gasoline. The fuselage has a special oil irrigation hole. It is necessary to add an appropriate amount of oil to the lubrication of gears such as crankshafts. It is necessary to exclude waste engine oil and re -irrigated new type of oil to ensure the machine’s machine’s high performance. Noise and jitter: The same horsepower is slightly larger than the noise and power of the outsourcing of the four -way ship. Easy maintenance: Because the external structure of the two -stroke ship is simple, the external aircraft is more convenient than the maintenance and maintenance. Use of fuel: The two -stroke machine uses hybrid fuel, that is, gasoline and engine oil are mixed in proportion, gasoline: motor oil = running -in period 25: 1. 50: 1 after the running -in period. For four -stroke fuel, please use gasoline above 92, and add the oil to the oil tank in the machine alone.

Precautions for shipping out of the ship

Secondary water -cooled ship engine is used strictly in accordance with the correct proportions of the two -stroke oil, car oil, gear oil, car oil, gear oil. Yamahas Er Chong's water -cooled ship's external engine startup machine must put the machine in water before starting (do not put the machine on the shore). If the outside of the air -cooled ship engine starts the machine, the four rushes of the four rushing engine oil must be added when the engine starts the machine. It is forbidden to run in the bucket,the total speed of the running -in period is not as high as five minutes !! The long -time idle speed may produce carbon deposits, which may burn the spark plug, which may cause difficulty in the later stages .....!!!
