SPECIFICATIONS

AC Charging Input: > 3000W

Application: Solar Power Storage

Brand Name: ChinTiyan

Certification: CE,RoHS,FCC

Connection: Other

Display screen: Yes

High-concerned chemical: None

Model Number: BP500A

Net Weight: > 50Kg

Nominal Capacity: 5120Wh

Origin: Mainland China

Replacement Battery: No

Set Type: Charger Sets

Size: 63*55*52CM

Solar Charging Input: 500W - 1000W

Type: LiFePO4

Please note: This industrial-grade energy storage system is a bespoke product with a lead time of 40–45 days. Please contact our customer service team before purchasing; we will provide you with professional pre-sales support. Thank you.

Specifications

Operating state: Discharge

Output voltage 230VAC/50Hz

Rated power 5,000W

150% overload Operation for 600 s possible

200% overload Operation for 100 s possible

250% overload Operation for 15 s possible

Peak power 10000W

Maximum short-circuit current 500 A (peak)

Permitted operating temperature -20°C to 45°C

Operating state: Charge

Input voltage 188–264 VAC / 50–60 Hz

Rated power 2500 W

PV input 120–430V 18A 3600W max

Charging time ~ 2.5Hrs(AC) - 1.5Hrs(PV)

Permitted operating temperature 0°C to 45°C

General information

Capacity 5,120 Wh

Battery Type LiFePO4

Weight 65 kg

Dimensions 622x454x513.4mm

Protection rating IP54

Protection class Class II / double-insulated

Noise emissions <45 dB(A)

Package: 1*5000W 5120Wh IP54 Waterproof Industrial Portable Power station LiFePO4 Generator Replace Diesel Generator
