Product Overview
SPECIFICATIONS
Application: Fishboat
Brand Name: ZRGAE,YAHATSU
Color: YAMAHA Gray Color
Condition: New, New
Control System: Tiller Control
Cylinders: 2
Displacement: 496 Cc
Engine: 2 STROKE, 2 STROKE
Engine Position: OUTBOARD
Engine type: 2 Cylinder Gasoline Engine
Fuel Type: Gasoline, Gaoline
High-concerned chemical: None
Model Number: T40S/L
Origin: Mainland China
Place of Origin: Zhejiang, China
Product Name: Gasoline Outboard Engine Boat Motor
Purpose: for manufacturing
Starting system: Manual
Warranty: 1 Year
| Characteristics | *T25J |
| Motor type | 2 Cylinder |
| Displacement | 496cc |
| Bore*Stroke | 72*61mm |
| Gear Ratio | 2.08 |
| Full throttle speed range | 4500~5500 |
| ldl ing rpm | 1100±50 |
| Max.PropShaft Output | 18.4kW(25HP) @5000rpm |
| Alternator output | 12V/6A With Rectifire/Regulator |
| Engine Transom Heigt(mm)S | 423mm,(16.7in) |
| Engine Transom Heigt(mm) L | 550mm,(21.7in) |
| Engine Transom Heigt(mm)XL | |
| Dry Weight(Kg.)S/L/XL | 53kg/54.5Kg |
| Starter | Electric or manual |
| Direction system | Remote/Manual |
| Trim&Tilt | Manual |
| Builtin Fuel Tank(L) | 24Lts. |
| Fuel Induction System | 1Carb |
| Additional accessories | Spare propeller Part kit Tools kit Fuel tank |
