Product Overview
SPECIFICATIONS
Application: Fishboat
Brand Name: YAHATSU
Color: YAMAHA Gray Color
Condition: New,New
Control System: Tiller Control
Cylinders: 2
Displacement: 362 Cc
Engine: 4 Stroke,4 STROKE
Engine Position: OUTBOARD
Engine type: 2 Cylinder Gasoline Engine
Fuel Type: Gasoline,Gaoline
Model Number: F20S/L
Place of Origin: Zhejiang, China
Product Name: Gasoline Outboard Engine Boat Motor
Purpose: for manufacturing
Starting system: Manual
Warranty: 1 Year
| Characteristics | F20 | F4 | F2.5 |
| Motor type | 2 Cylinder | 1 Cylinder | 1 Cylinder |
| Displacement | 139cc | 139cc | 72cc |
| Bore*Stroke | 63*58.1mm | 62*46mm | 54*31.5mm |
| Compression ratio | 8.90 | 8.90 | 9.00 |
| Full throttle speed range | 20HP@5500rpm | 4HP@5500rpm | 2.5HP@5500rpm |
| Max.rpm Range | 4000-5000 | 4000-5000 | 5250-5750 |
| Fuel Induction System | OHV | OHV | OHV |
| Intake | carburetor | carburetor | carburetor |
| Exhaust | Above Prop pele r | Above Prop pele r | Above Prop pele r |
| Cooling | |||
| lgn ii on System | CDI | CDI | TCI |
| Alternator output | 6Amp(Optional:Requi ers Charging Kit) | ||
| Starter | Manual | Manual | Manual |
| Engine Oil Capacity | 600ml | 600ml | 350ml |
| Gear Ratio | 2.08 | 2.08 | 2.08 |
| GearShift | |||
| Shaft Length | S=17.2"L=22.2" | S=17.1"L=22.1" | S=15" |
| Dry Weight | 51kg/61kg | 27kg | 17kg |
| Steering Angle(maximum) | 90 from center, either direction | 360 from center, either direction | |
