Product Overview
SPECIFICATIONS
Application: Fishboat
Brand Name: YAHATSU
Color: YAMAHA Gray Color
Condition: New,New
Control System: Tiller Control
Cylinders: 2
Dimensions (L x W x H) (mm): 60*52
Displacement: 294 Cc
Engine: 2 STROKE,2 STROKE
Engine Position: OUTBOARD
Engine type: 2 Cylinder Gasoline Engine
Fuel Type: Gasoline,Gaoline
Model Number: T18S/L
Place of Origin: Zhejiang, China
Product Name: Gasoline Outboard Engine Boat Motor
Purpose: for manufacturing
Starting system: Manual
Warranty: 1 Year
| Characteristics | T20 | T9.8 |
| Motor type | 2 Cylinder | 2 Cylinder |
| Displacement | 294cc | 169cc |
| Bore*Stroke | 60*52mm | 50*43mm |
| Gear Ratio | 1.85 | 2.08 |
| Full throttle speed range | 5200~5800 | 5000-6000 |
| ldl ing rpm | 800~950 | 750±50 |
| Max.PropShaft Output | 13.2KW(18HP) @5000rpm | 7.2KW(9.8HP) @5000rpm |
| Alternator output | 12V/6A With/Without Rectifire/Regulator |
12V/6A With/Without Rectifire/Regulator |
| Engine Transom Heigt(mm)S | 435mm(17.1") | 435mm(17.2") |
| Engine Transom Heigt(mm) L | 562mm(22.1") | 562mm(22.2") |
| Engine Transom Heigt(mm)XL | *689mm(27.1") | *689mm(27.1") |
| Dry Weight(Kg.)S/L/XL | 41kg/42kg | 29Kg/30kg |
| Starter | manual | manual |
| Direction system | manual | manual |
| Trim&Tilt | manual | manual |
| Builtin Fuel Tank(L) | 12Lts | 12Lts. |
| Fuel Induction System | 1Carb | 1Carb |
| Additional accessories | Spare propeller Part kit Tools kit Fuel tank |
Spare propeller Part kit Tools kit Fuel tank |
