SPECIFICATIONS

AC Charging Input: > 3000W

Application: Home Energy

Brand Name: ChinTiyan

Certification: CE,RoHS,FCC

Connection: Other

Display screen: Yes

High-concerned chemical: None

Model Number: BP500A

Net Weight: > 50Kg

Nominal Capacity: 5120Wh

Origin: Mainland China

Replacement Battery: No

Set Type: Charger Sets

Size: 57*38*63CM

Solar Charging Input: 500W - 1000W

Type: LiFePO4

Please note: This industrial-grade energy storage system is a bespoke product with a lead time of 10 days. Please contact our customer service team before purchasing; we will provide you with professional pre-sales support. Thank you.

Specifications

Nominal Output Power : 5000 W

Surge Power :10000 W

Wave Form:Pure Sine Wave

Output Frequency and Voltage : 50Hz/60Hz; 230V/240V; L+N+PE

Overload Capacity (Battery Mode) :60s@110%~120% load, 10s@120%~130% load, 3s@130%~150% load, 0.2s>150% load

Battery Mode Energy :5210 Wh

Battery Type :LiFePO4

Life Cycle :>6000 Cycles (Test conditions: 0.5C Charging/Discharging @25°C)

Max.AC Input Power :4600 W

Max.PV Input Power : 6000 W

Max.PV Input Current :18 A

MPPT Range @Operating Voltage :120-430 V

Switch Time :10 ms(normal mode) / 10 ms(UPS mode)

Output Jack : Waterproof 10A, Waterproof 16A

HMI :LCD

Dimensions(W*H*D) : 562*377*625mm

Net Weight : 62 kg

Charging Temperature Range :0~55°C

Discharging Temperature Range: -20~55°C

Package: 1pcs BH0505C 5000W 5210Wh Trolley-Style Portable Power Station
