SPECIFICATIONS

Blades number: 3/5

Brand Name: Bessent

Model Number: NE-300S

Output Voltage: 12V/24V

Place of Origin: Jiangsu, China

Product Name: Wind Turbine

Rated Power: 300w

Rated Voltage: 12V/24V

Rated Wind Speed: 11m/s

Start up Wind Speed: 2m/s

Start wind speed: 2m/s

Survival Wind Speed: 50m/s

Wheel diameter: 1.35m

Wheel height: 3.5m

Working temperature: -40°C~80℃

rotor diameter: 1.35m

Specification

Rated power	100W	200W	300W	400W
Maximum power	130W	220W	310W	410W
Rated voltage	12/24V	12/24V	12/24V	12/24V
Start up wind speed	2m/s	2m/s	2m/s	2m/s
Rated wind speed	10m/s	11.5m/s	13m/s	13m/s
Survival wind speed	55m/s	55m/s	55m/s	55m/s
Wheel diameter	1.2m	1.3m	1.3m	1.4m
Wheel height	3.5m	3.5m	3.5m	3.5m
Blades number	3	3	3/5	3/5
Gross weight	5kg	5.2kg	5.6kg	5.8kg
Blades material	Nylon fiber
Generator	Three phase permanent magnet AC generator/maglev generator
Control system	Electromagnet/wind wheel yaw
Speed regulation	Automatically adjust windward direction
Working temperature	-40°C~80℃
